What is the smart white board?
Multimedia teaching one machine is a multifunctional interactive teaching equipment with the infrared touch technology, intelligent Office teaching software, multimedia network communication technology, High-definition Flat panel display technology and many other technologies in one, which integrated projector, electronic whiteboard, computer, TV, touch function and other equipment in one .
Overview
1, Aluminum frame, steel nano surface.
2, An array of inputs points including HDMI,USB,and OPS ...
3, 15W*2 professional education acoustic ,suitable for classrooms and conference centers
4, 4k screen 4k resolusionare able to handle the most demanding media-centric presentations
5, 4mm tempered glass for screen protection, 10-points IR touch technology enjoys freely interaction
| Specifications | |||||||
| Model No. | MJK-AD65WB | ||||||
| Panel size | 65" TFT-LCD | ||||||
| Display area(mm)/mode | 1508.0 x 878.0(mm 16:9 | ||||||
| Maximum resolution | 1920×1080 | ||||||
| Display color | 16.7M | ||||||
| Pixel Pitch(mm) | 0.744(H)×0.744(V) | ||||||
| Brightness (nits) | 500cd/ | ||||||
| Contrast | 5000:1 | ||||||
| Visual angle | 178°/178° | ||||||
| Response time | 8ms | ||||||
| Horizontal frequency | 50-70KHZ | ||||||
| Vertical frequency | 56-75KHZ | ||||||
| Life(hrs) | >60,000(hrs) | ||||||
| Touch Panel | |||||||
| Specification | Infrared touch | ||||||
| Positioning | ±2mms | ||||||
| accuracy | |||||||
| Transmittance | ≥92% | ||||||
| Hardness | 7H | ||||||
| Click manner | double point/mult-point(optional) | ||||||
| Response time | 10ms | ||||||
| Output Resolution | 8192*8192 | ||||||
| Life time | Single point of more | ||||||
| than 600 million times | |||||||
| Input and output | |||||||
| VGA input | 2 | ||||||
| CVBS input | 2 | ||||||
| YPbPr input | 1 | ||||||
| TV | 1 | ||||||
| HD | 4 | ||||||
| USB2.0 | 6 | ||||||
| LAN | 1 | ||||||
| PC Audio | 1 | ||||||
| Audio(L/R) input | 1 | ||||||
| Audio(L/R) output | 1 | ||||||
| Speaker | 2×10W(8 ohm) | ||||||
| Video | |||||||
| Color system | PAL/NTSC/SECAM | ||||||
| Compatible HD input/DVI | 480P,576P,720P,1080I,1080P | ||||||
| 3D Comb filter | Yes | ||||||
| Video reduction noise | Yes | ||||||
| OSD display( screen menu display) | |||||||
| Menu language | Chinese/English | ||||||
| Computer | |||||||
| Main chipset | Intel H61 | ||||||
| CPU | Intel I3/I5/I7 | ||||||
| System bus frequency | 800/1066/1333 MHz | ||||||
| Graphics card | Integrated | ||||||
| Audio card | Integrated AC97 | ||||||
| Network card | Integrated 10/100/1000M adaptive | ||||||
| Memory | 2G DDRIII (max 4G) | ||||||
| Hard Disk | 320G SATA | ||||||
| WIFI | Optional | ||||||
| Bluetooth | Optional | ||||||
| Operation system | Windows 7 | ||||||
| Power | |||||||
| Power supply | AC100V~240V,50/60Hz | ||||||
| Maximum power consumption | 400W | ||||||
| Standby power consumption | 3W | ||||||
| Temperature | |||||||
| Working temperature | 0°C~50°C | ||||||
| Storage temperature | -10°C~60°C | ||||||
| Working humidity | 20%~80% | ||||||
| Storage humidity | 5%~95% | ||||||
| Appearance | |||||||
| Cabinet color/appearance | White, black, customized | ||||||
| Cabinet material | SPCC/Aluminum/Customized | ||||||
| Installation | Floor-standing |
||||||
MJK ELECTRONICS CO., LTD
was established in 2005. Our company is located in shenzhen, China.Our company is a professional Hi-Tech enterprise engaged in all kinds of LCD digital signage displays such as outdoor kiosks,interactive touch kiosks, touch screen table ,wall mounted displays,floor standing displays,,LCD monitor ,videowall,etc.which are the most widely using media in retail, shopping center, restaurant, hotel, bank, building, airport,showroom etc.
We have a professional and precise technical support team, including software development engineer, electronic engineer, construction engineer, who are outstanding in the digital signage.As one of the leading company in digital signage,MJK offers very innovative, stylish, and full-function products, which are welcome by the clients from over fifty countries and areas.
MJK always takes the strict QMS system to control quality for Zero Fault, so as to meet various standards from clients worldwide. Our products acquire CE, FCC, ROHS,3C certifications so far.
Having rich experience in OEM & ODM cooperation, we are capable of offering you factory price with guaranteed quality as well as complete after-sale service. We have and will always try our best to meet every possible demand of our customers.
Enterprise Vision
We create the best performance to repay the society
Our profassional team and technical capability lead product direction in the future
Be an excellent innovative and competitive company in global market
Our brand has adequate influence in the industry and is well-know in China
We create unique culture and will be the model of Industry
The products and services we offer should be the most reliant and popular in the market
We have excellent team and offer them great workplace and remuneration
Our products are sold all over the world, you can rest assured.
