Main features
| OS: | Android 5.1/7.1 | ||||||||
Hardware |
CPU Options: | RK3188 Quad-core ARM Cortex-A9,1.6GHz | |||||||
| RK3288 Quad-core ARM Cortex-A17,1.8GHz | |||||||||
| RK3399 Dual-core Cortex-A72
2.0GHz + Quad-core Cortex-A53 1.5GHz |
|||||||||
| RAM: | 1GB/2GB/4GB/8GB | ||||||||
| Nand Flash: | Standard 8GB(16GB/32GB optional) | ||||||||
| WiFi module: | Support WIFI 802.11b/g/n | ||||||||
| 3G/4G: | Support 3G/4G (optional) | ||||||||
| GPS: | optional | ||||||||
| BT module: | 4.0 optional | ||||||||
| Managing software: | We can offer professional managing software. You may use your own app. | ||||||||
| Playlist editor: | Multimedia contents can play by playlist mode | ||||||||
| Scheduling playback: |
Publish task by calendar, then the appointed terminal/terminals would play accordingly. |
||||||||
| Multi-languages: |
Support English, French, German, Italian, Swedish, Denmark, Portuguese, Spanish, Japanese....etc |
||||||||
| Multizone display: |
Video, photo, text, ppt, word, excel, flash, rss, wheather, clock, website can be display on different areas. |
||||||||
| Timing function: |
Set time power ON/OFF and automatically display and loop, 7days and 24 hours no manual operation. |
||||||||
| Protection plate: | Files on SD card can be protected by protection plate from stolen. | ||||||||
| video/picture rotation: | 90/180/270 degree. (vertical display or horizontal display) | ||||||||
| Advanced functions: | Support play log, customer logo | ||||||||
| Display type: | Horizontal or vertical/ landscape or portrait | ||||||||
| Two speakers: | Built-in stereo speakers (2x5W) | ||||||||
| Files update: |
Files can be transmitted to SD card memory automatically from server throught network. |
||||||||
| Touch screen: | Optional | ||||||||
| Network options: | LAN/WIFI/3G/4G | ||||||||
| Management software: |
With management software installed in server by which to control and group manage all terminals |
||||||||
| Rolling caption: | Support running marquee function (roll caption, text bar). | ||||||||
| Support memory size: | 8GB-500GB | ||||||||
| Accessories: | User Manual, Adapter, Remote Control, keys, USB dongle, mouting parts | ||||||||
| Warranty: | Standard one year, extra warranty is optional. | ||||||||
Welcome to contact us and get user manual for reference.
More specs
| LCD screen specs | Model number | MJK-AD14.9B |
| Screen size: | 14.9" | |
| Display proportion: | 16:5 | |
| Resolution(Pixel): | 1280*390 | |
| Display color: | 16.7 M | |
| Response time : | 10ms | |
| Luminance: | 700 cd/m2 (high brightness optional) | |
| Contrast ratio: | 500:1 | |
| View angel (L/R/U/D): | 45/75/80/80 | |
| Media Formats | Video: | MPEG1/2/4,AVI,H.264,MOV,MKV,RMVB,RM,TS...etc |
| Audio: |
MP3, WMA, WAV, EAAC+, MP2 dec, AC3, FLAC, APE, BSAC |
|
| Picture: | JPEG ,BMP ,GIF ,PNG | |
| Others: | WORD, EXCEL, PPT, HTML | |
| Power supply | AC Input: | 110-240V |
| DC Output: | 12V, 3A | |
| Appearance | Color option: | Black or optional |
| Housing material: | Whole metal housing (front tempered glass panel optional) |
|
| I/O interface: | 1*SD card slot,1*LAN port,2*USB output,Power switch | |
| Installation: | Wall-mounting/ shelf mounting/ desktop | |
| Unit dimensions: | 423*173*51MM | |
| Active display area: | 361*112MM | |
| Packing details | Carton size: | 530*550*280 MM |
| Quantity/Carton: | 4PCS/carton | |
| Gross Weight: | 15KGS |
The reason why choose us?
1,We have our own ERP of the main manufacturer for digital signage and lcd video wall.
2, We could provide OEM/ODM service for all kinds of customers. Our proffesional support team will service onlin 24 hours for customers.
3, We have a very strong quality control Samples are always available for checking quality and can be dispatched to you very quickly.
4, Samples are always available for checking quality and can be dispatched to you very quickly.
6, Design ability: artwork/ Instruction manual/ product design according to customer's requirement.
7. We have our own ERP systems : Shorten lead times at low cost with responsive production planning
8, Warranty (1-3 year)
MJK ELECTRONICS CO., LTD
was established in 2005. Our company is located in shenzhen, China.Our company is a professional Hi-Tech enterprise engaged in all kinds of LCD digital signage displays such as outdoor kiosks,interactive touch kiosks, touch screen table ,wall mounted displays,floor standing displays,,LCD monitor ,videowall,etc.which are the most widely using media in retail, shopping center, restaurant, hotel, bank, building, airport,showroom etc.
We have a professional and precise technical support team, including software development engineer, electronic engineer, construction engineer, who are outstanding in the digital signage.As one of the leading company in digital signage,MJK offers very innovative, stylish, and full-function products, which are welcome by the clients from over fifty countries and areas.
MJK always takes the strict QMS system to control quality for Zero Fault, so as to meet various standards from clients worldwide. Our products acquire CE, FCC, ROHS,3C certifications so far.
Having rich experience in OEM & ODM cooperation, we are capable of offering you factory price with guaranteed quality as well as complete after-sale service. We have and will always try our best to meet every possible demand of our customers.
